Industrial Lighting

Radar-Sensor UFO High Bay

High-quality LED lighting solution for commercial applications

CE RoHS 5-Year Warranty

It detects the ambient illuminance and automatically switches the luminaire on when the space is occupied, then holds it at reduced output or switches it off after a set delay once unoccupied.

High-Efficiency Output

High efficacy — more light, less energy consumption

Certified for Your Market

CE · RoHS · ISO 9001 certified manufacturing

Built to Last

50,000 hrs lifespan · 5 years warranty · MOQ 100 pcs

Technical Specifications

Power100W/150W/200W/300W
Input VoltageAC 100-277V 50/60Hz
Dimensionsφ240*91mm/φ335*103m/φ335*112mm/φ335*112mm
Cutout Size-
CCT Options5000K/6000K
CRIRa > 80
Beam Angle-
Efficacy140 lm/W
UGR< 19
InstallationThreaded Rod Mounting/ Chain Mounting
Dimming-
IP RatingIP65
MaterialDie-Cast Aluminum Housing
Warranty5-year warranty
Lifespan50,000 hours (L70 @ 25°C)
MOQ100 pcs
CertificationsCE, RoHS

Available Options

Dimming Control
Non-dim / 0-10V / DALI-2
Beam Angle
24° / 38° / 60°
