Deep cup anti-glare ceiling lamp

High-quality LED lighting solution for commercial applications

CE RoHS 5-Year Warranty

The HL-D003 is a high-quality LED lighting solution designed for commercial and industrial applications. It offers excellent energy efficiency, long lifespan, and reliable performance.

High-Efficiency Output

High efficacy — more light, less energy consumption

Certified for Your Market

CE · RoHS · ISO 9001 certified manufacturing

Built to Last

50,000 hrs lifespan · 5 years warranty · MOQ 100 pcs

Technical Specifications

Power	30W
Input Voltage	AC 100-277V 50/60Hz
Dimensions	φ159*89mm
Cutout Size	φ146mm
CCT Options	3000K/4000K/6000K/8000K/10000K
CRI	Ra ＞90/Ra ＞90
Beam Angle	15°/24°/36°/60°
Efficacy	120 lm/W
UGR	< 19
Installation	Recessed
Dimming	On-offtriacl0-10V/Dali dimming avalable
IP Rating	IP20
Material	Die-cast aluminum + PC diffuser
Warranty	5-year warranty
Lifespan	50,000 hours (L70 @ 25°C)
MOQ	100 pcs
Certifications	ETL,CE, RoHS
